Course Fee


New Student Discount


Returning Student Discount


Training Details

Duration: 2 Days
Time: 9:00 AM - 7:00 PM

Course Overview

Learning Objectives: IP Based/Analog Systems (NVR/DVR), Various Types of CCTV Cameras, Focal Lengths, F Stops, Image Sensor, IP Ratings, Optical Cables, Power Cables, Power Adapter, PoE Switch, Centralized Power Supply, Local & Remote Viewing (Public IP, DDNS, & Cloud See), Configure Router: Port Forwarding, DMZ and much more…


The implementation of CCTV cameras whether traditional Analog or IP Based will require additional skill sets in wired and wireless as it will play a significant role in the deployment of IP cameras, PC based NVR systems, Wireless Citywide CCTV, and the configuration of DVR/NVR systems for both local and remote access.

  • Basic computer skills in Hardware and Software on either Mac or PC.
  • Basic Networking: Wired and Wireless or Networking Essentials Equivalent


  • Unlimited Refresher Class (Validity : 1 year)
  • Certificate of Course Completion
  • References Materials (PDF)
  • Software Evaluation Copy
  • Other Add-ons

Course Outline


  • What is CCTV?
  • History
  • Use and Benefits
  • Philippine CCTV Cameras for Security Act of 2012

Certification for Quality

IP and IK Ratings Explained

CCTV Equipment Basics

Types of CCTV Recorder

  • Multiplexer (Non-Recorder)
  • Standalone Digital Video Recorded
  • PC Based Digital Video Recorder
  • Standalone Network Video Recorder
  • PC Based Network Video Recorder
  • Hybrid DVR

Recorder Hard Disk Drive (HDD) Requirement

Video Compression Formats

  • MPEG
  • MPEG4
  • H.264
  • H.265

Different Types of CCTV Cameras

  • Dome Camera
  • Bullet Camera
  • Covert/Discreet
  • Varifocal Camera
  • Auto Iris Lens
  • OSD Cameras
  • Box Camera
  • PTZ (Pan Tilt Zoom) / Speed Domes
  • IP/Network Camera
  • Wireless IP Camera
  • IVS Camera (Intelligent Video Surveillance System)

Understanding Focal Lengths

  • 2.8mm
  • 3.6mm
  • 4 mm
  • 6mm
  • 8mm
  • 12mm

Image Sensor Comparison

  • CCD
  • CMOS
  • Image Sensor Sizes

Lights and its Problems

  • Back Light Compensation (BLC)
  • Wide Dynamic Range (WDR) / Digital Wide Dynamic Range (D-WDR)
  • Highlight Compensation (HLC)

Working with Analog and IP Based PTZ

  • RS485 Basics
  • Installing and Configuring Analog and IP Based PTZ
  • Installing and Configuring Analog and IP Based PTZ Controller

Display and Recording Resolutions

Optical and Data Cables

  • RG59 Cable / RG59 Siamese Cable
  • RG6 Cable / RG6 Siamese Cable
  • CAT5e UTP Cable
  • CAT6 UTP Cable
  • Maximum Cable Distances

Optical Adapters

  • BNC
  • Passive Balun
  • Active Balun

Power Source

  • Power Adapter
  • Centralized Power Distribution Unit
  • PoE Switch and Injector

Optical Cable Crimping / Termination

Power Cable Crimping / Termination

Installing CCTV Recorders

  • Standalone DVR
  • Standalone NVR
  • PC-Based NVR

Recorder Management and Configuration

  • Continuous Recording
  • Scheduled Recording
  • Motion Detection Recording
  • Video Playback/Review
  • Video Backup
  • User Account Management

Local & Remote Access (Public IP, DYNDNS, Cloud P2P)

  • LAN Access via Web Browser and Client Software
  • Remote Access via Public IP / Leased IP
  • Remote Access via DYNDNS
  • Remote Access via Cloud P2P

Site Survey

Design & Commissioning

Proposal & Costing

Introduction to Setting up and Configuring Citywide Wireless CCTV (Bonus)
